RCF NX 10-SMA Stage Monitor

The NX 10-SMA is equipped with new high power 400 W digital amplifier and a newly designed 10 "" coaxial neodymium transducer that guarantees outstanding audio quality and definition as well as an extremely lightweight of the final system.

The NX 10-SMA can be also used as a portable PA system, thanks to the rugged powder coated steel pole mount installed on the side. In order to control the response of the speaker in such different applications, RCF has incorporated two special Equalization Modes :

• Floor, for stage monitoring;
• Free Field, for the use of the speakers as a stand-alone PA system.

The cabinet is made of Baltic Birch plywood, finished with an extremely resistant paint for an extensive use on the road.
An ergonomic side handle, integrated with the input panel, is provided for an easier transport of the speaker.

Coaxial Neodymium Trasducers

The newly designed coaxial neodymium transducers guarantee an outstanding audio quality and definition as well as an extremely lightweight of the final system.

Complete Absence Of Feedback

The advantages of the coaxial transducers are the complete absence of feedback and, thanks to the coherent single spherical wavefront with a perfect dispersion control, a perfect listening in every position.

Single Neodymium Ring

The large sized single neodymium ring magnet provides an extremely high flux density and BL factor.

Hyper-Vented Basket

Both the new transducers are equipped with a new hyper-vented basket and magnetic assembly that provide an excellent heat dissipation and lower power compression.

Amplification

The NX Coaxial Stage Monitors are provided with brand new digital amplifiers with powerful DSP processing. A 400 W module that delivers 300 W for the low frequencies and 100 W for the high frequencies powers the NX 10-SMA. The NX 12-SMA and NX 15-SMA are equipped with a 700 W amplifier, 500 W feed the low frequencies and 200 W are used for the high frequencies.

The input board is fully equipped in order to configure the stage monitors for any stage situation.

• XLR Input and Output Link
• Jack Input
• Volume
• Input Sensitivity Switch
• Free Field – Floor Switch
• Status LEDs
• Powercon AC Input and Output Link

Ergonomic Handle

Cabinets are made of Baltic Birch plywood, finished with an extremely resistant paint for an extensive use on the road. An ergonomic side handle, integrated with the input panel, is provided for an easier transport.

Maximum Flexibility

NX Series maximum flexibility philosophy has been maintained for these two new additions; it is possible, in fact, to use the NX 10SMA, NX 12SMA and NX 15SMA as a portable PA system, thanks to the rugged powder coated steel pole mount installed on the side.

Special Equalizations

In order to control the response of the speakers in such different applications, RCF has incorporated two special Equalization Modes:

• Floor, for stage monitoring;
• Free Field, for the use of the speakers as a standalone PA system.
