Shure SM86
Cardioid Dynamic Vocal Microphone
The Shure SM86 is a unidirectional (cardioid) condenser vocal microphone for professional use in live performance. An extremely rugged microphone, the SM86 withstands the rigors of touring while delivering a clear, studio-quality sound.
A cardioid pickup pattern isolates the main sound source while minimizing unwanted background noise. The built-in three-point shock mount minimizes handling noise, and a two-stage pop filter reduces wind and breath "pop" noise.
Condenser cartridge for studio quality sound
Tailored frequency response for a clear reproduction of vocals
Rugged construction withstands the rigors of touring sound
Cardioid polar pattern minimizes unwanted background noise
Excellent choice for stage monitors and personal monitors
Built-in three-point shock mount minimizes handling noise
Two-stage "pop" filter reduces wind and breath noise
Polar Pattern : Cardioid
Output Impedance : 150 Ohms at 1 kHz Recommended minimum load impedance : 600 Ohms
Sensitivity (at 1,000 Hz) : Open Circuit Voltage : -50 dBV/Pa (3.15 mV) (1 Pa = 94 dB SPL)
Output Clipping Level : 1000 Ohm Load at 1,000 Hz : +3 dBV (1.41 V)
Maximum SPL (at 1,000 Hz) : 1000 ohm load (1% THD) : 147 dB
Self-Noise : 23 dB typical, A-weighted
Dynamic Range (1000 ohms) : 124 dB (maximum SPL to A-weighted noise level
Signal-to-Noise Ratio : 71 dB at 94 dB SPL (IEC 651)* *S/N ratio is difference between 94 dB SPL and equivalent SPL of self-noise A-weighted.
Polarity : Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of the output connector.
Power : Phantom Supply Requirement : 11 to 52 Vdc, positive at both pins 2 and 3 Current Drain : 5.2 mA
Connector : Three-pin (XLR) professional audio
Case : Dark gray enamel-painted steel with matte-finished silver colored steel grille
SKU
SHR-SM86
Brand
Shure
Weight
1.000000
