10-Channel Mixing Console w/ Multi-FX & Recording
was $529.00 Special Price $399.99
In stock
SKU
RCF-F10XR

RCF’s next generation F Series mixers builds on the rich analog legacy found in the professional E Series, featuring high quality sound in four formats from 6 to 16 channels. A powerful tool for the musician and the sound enthusiast, entirely conceived and designed by the RCF R&D team. Housed in a sturdy metal chassis, each mixer features a full balanced audio path from input to output and the unique PRO DSP FX: 16 professional effects such as Reverbs (Halls, Rooms, Plates, Spring), Delays (Mono, Stereo and Multitap), Chorus, Flangers and Echoes. The models F-10XR, F-12XR, and F-16XR, include an USB audio interface, for stereo recording on computer-based DAW and 2-channel playback

State Of The Art Eq

State-of-the-art 3 band EQ on mono channels, 2 bands EQ on stereo channels for precise and exquisitely transparent shaping of sound.

High Quality Preamplifiers

High quality preamplifiers with phantom power, inspired by the E-Series Mixers, offer high quality sound and dynamics. Line level signals are less noisy when connected using the separate line input jack socket.

  • 4 Mic Preamp Inputs, 2 Mono Line Inputs
  • 4 Stereo Line Inputs
  • Pro Dsp Fx Onboard With 16 Presets
  • Stereo Recording And Playback Via Usb Port
  • 2 Single Control Compressors
  • Balanced Main Output +28 Db (Stereo Xlr + Trs)
  • 1 Aux/Fx (Post)
  • Sturdy Metal Chassis
  • External Universal Power Supply

Auxiliary Sends

  • Fx Post : 1

Compressors

  • Rcf Compressors : N° 2 Single Control Compressors On Channels 1&2

Electrical Specifications

  • Power Consumption (W) : 18 W
  • Power Supply : External
  • Voltage Requirements : 100 V - 240 V
  • Frequency Response : 20 Hz ÷ 20 Khz
  • Thd+N, 20db Gain, 0dbu Out (% A-Weighted) :  <0,02

Eq

  • Description : High : +/-15 Db @ 10 Khz Shelving Mid : +/-15 Db @ 1,250 Khz Bell Low : +/-15 Db @ 100 Hz Shelving
  • Input Channels Eq : 2 Shelving / 1 Generic

Inputs

  • Gain Range : 0 Db ÷ -50 Db
  • Gain Selection : 20 Db ÷ -30 Db
  • Mic Inputs Impedance (Kohm) : 14 Kohm
  • Line : 2
  • Line Input Impedance (Kohm) : 21 Kohm
  • Low Cut : 80 Hz
  • Mic : 4
  • Phantom Power +48v : Yes
  • Stereo Line : 4
  • Stereo Line Gain Selection : 20 Db ÷ -30 Db
  • Stereo Line Input Impedance : 15 Kohm

Internal Effects

  • Send Effects : 1

Other Features

  • Footswitch : Yes

Outputs

  • Aux Output : 1
  • Control Room : Yes
  • Fx Send : 1
  • Main Mix : 1
  • Phones : 1

Outputs Specifications

  • Aux Out Level (Dbu) : 28 Dbu
  • Main Out Level (Dbu) : 28 Dbu
  • Phones Out Impedance (Ohm) : 150 Ohm

Physical Specifications

  • Cabinet/Case Material : Metal
  • Color : Black
  • Shipping Informations
  • Package Depth : 345 Mm / 13.58 Inches
  • Package Height : 130 Mm / 5.12 Inches
  • Package Width : 400 Mm / 15.75 Inches

Size

  • Depth : 275 Mm / 10.83 Inches
  • Height : 82 Mm / 3.23 Inches
  • Width : 294 Mm / 11.57 Inches

Standard Compliance

  • Ce Marking : Yes
  • Usb Audio
  • Play Trk : 2
  • Rec Trk : 2
  • Supported Sample Rate (Khz) : 44.1, 48.0
  • Type : B
SKU RCF-F10XR
Brand RCF
Weight 8.380000
