The VRX932LAP is a powered, lightweight, compact 12"" two-way line-array speaker system designed for use in arrays of up to five units. VRX932LAP is the ideal choice when line-array performance is needed but the venue size doesn't call for the veray long-throw characteristics of larger line-arrays and a fast and easy setup is vital
JBL Bags VRX932LAP-BAG
Padded carry bag for VRX932LAP. 1200D Nylon (black) with waterproof backing, soft tricot fabric interior, 10mm padding, exterior carry handles with Velcro wrap, large exterior storage pocket (1"" gusset).
Built-in JBL Drivepack DPC-2 amplifier module designed by Crown provides 1750 Watts of peak Power. DSP based resident input module provides system optimization and EQ functionality.
JBL's exclusive neodymium magned Differential Drive® woofer for high-power capacity and light-weight.
VRX932LAP features 3 x 2408J Annular Ring Diaphragm HF drivers. The 2408 represents the latest in JBL Professional compression driver design.
Constant Curvature waveguide for unprecedented array coherence.
Integral rigging hardware for simple connection of enclosures and optional array frame. Dual angle pole socket for aiming flexibility.
Power Rating: 1750 Watts Peak, 875 Watts Continuous
Frequency Range : 57 Hz - 20 kHz (-10 dB)
Frequency Response : 75 Hz - 20 Hz (+/-3db)
Maximum Peak Output : 136 dB SPL at 1m
Coverage Pattern : 100 x 15 nominal
DPC-2 Output as (Continuous IED shaped pink noise into rated load impedance) : LF: 750 Watts, HF: 125 Watts
DPC-2 Output Sectoin : LF: Dual-Bridged Technology™, Class D
Autio Input Connector : XLR with loop through
LF Driver : 1 x JBL 2262FF 305 mm (12 in) neodymium magnet
HF Driver : 3 x JBL 2408J, 38 mm (1.5 in)
User Controls : Input Attenuator (0-16 dB)
Signal Processings : DSP based, resident in Input Module
AC Power Operating Range : 90-132 VAC or 216-264 VAC, 50/60 Hz
AC Input Connector : Neutrik PowerCon (NAC 3MPA)
AC Loop Through Connector : Neutrik PowerCon (NAC 3MPB)
AC Current Requirements : 6A per system at 120V, 3A per system at 240V
Enclosure : 25/15 mm, 11-ply birch plywood
Suspension / Mounting : Optional VRX-AF line array frame kit, 10mm forged eyebolts or internal dual angle 36mm pole mount cup for pole or tripod mounting
Finish : Black DuraFlex finish
Grille : Powder coated, black, 16-gauge perforated steel with with acoustically transparent foam
JBL Bags VRX932LAP-BAG
The ultimate padded carry bag for the VRX932LAP.
Cover constructed of 1200D Nylon with waterproof backing.
10mm padding and a soft Tricot fabric interior provide complete protection.
Exterior lifting handles with Velco wrap allow for superior mobility and functionality.
Large external storage pocket with 1" gusset provides generous storage space.
Includes provision for fastening (2x) VRX928LAP-BAG to a VRX Sub to create the ultimate mobile system.
