ColorKey Inceptor Panel FX LED Effect Panel Light

ColorKey Inceptor Panel FX LED Effect Panel Light

ColorKey Inceptor Panel FX LED Effect Panel Light

LED Effect Panel Light
$599.99
Out of stock
SKU
CLR-CKU4110

The ColorKey Inceptor Panel FX is a high-output LED effects and wash fixture engineered for designers who demand both power and flexibility in a single platform.

At its core is a powerful RGB plus cool white/ warm white LED system.

Independent RGB pixel zones and dedicated white segments deliver deep color saturation, precise tunable whites, and rich warmth. Blend the white channels to dial in anything from clean neutral tones to soft tungsten-style glow.

Whether on live stage productions, in venue designs, or as retail and hospitality accent lighting, the ColorKey Inceptor Panel FX adapts effortlessly to modern creative demands.

ActiveFrost electronic diffusion glass allows designers to shift between clear and frosted output instantly.

Unlike traditional mechanical systems, ActiveFrost uses electronic optical control. One moment the panel delivers sharp LED intensity and the next, smooth sophisticated diffusion.

Multi-zone pixel architecture unlocks advanced programming possibilities, turning the panel into a dynamic source of animated eye candy.

Independent RGB segments create sweeping gradients and motion-driven effects that add depth and movement to any rig, while the dedicated cool and warm white zones provide flexible color temperature control, rich amber tones, or clean white illumination.

Smooth 0–100% dimming and adjustable strobe effects add further creative control. The panel also performs as a powerful blinder, delivering audience-punching output when maximum impact is required.

Designed for real-world production environments.

Built for seamless integration, the Inceptor Panel FX connects effortlessly into touring or permanent systems and scales from simple plug-and-play setups to fully detailed pixel programming. An intuitive onboard display keeps configuration fast and straightforward, while multiple control modes ensure it adapts easily to any show environment.

A removable mounting yoke with rubberized feet enables stable floor placement and precise tilt adjustment when hung. The included Omega bracket can attach directly to the fixture body or to the yoke, for truss-mounting options to suit a wide range of scenarios.

From vibrant pixel effects to seamless wide washes, the ColorKey Inceptor Panel FX delivers versatility without compromise. A modern lighting tool designed to evolve with your creativity.

  • High-output pixel-mapped LED wash effects, strobe, and blinder panel with advanced color control
  • ActiveFrost electronic diffusion instantly switches between crisp pixel effects and smooth frosted wash
  • RGB plus CW/WW LED engine delivers vivid color, tunable white, and rich warm tungsten tones
  • Advanced multi-segment pixel control for dynamic chases, gradients, and detailed eye candy effects
  • Dual Omega mounting positions and professional DMX/PowerCON connectivity for flexible installations
  • ActiveFrost electronic diffusion instantly switches between clear and frosted output
  • High-output RGB + Cool/Warm White LED engine
  • Dedicated warm white channel for amber tones and tungsten-style looks
  • Advanced multi-segment pixel control for dynamic effects and detailed programming
  • Wide wash coverage with up to 158° field angle
  • Smooth 0–100% dimming and adjustable strobe effects
  • Dual Omega bracket mounting positions for flexible installation
  • Professional connectivity with 3-pin & 5-pin DMX and PowerCON in/out
  • Multiple DMX modes from simple control to full pixel-level operation

Light Source

RGB LEDs

  • 600 × 0.5W RGB (20-segment)
  • Illuminance : 545 lux @ 2m
  • 280 × 0.5W RGB (40-segment)
  • Illuminance : 340 lux @ 2m
  • Combined RGB Illuminance : 885 Lux @ 2M

White LEDs

  • 240 × 1W Warm White / Cool White (10-segment)
  • Warm White Color Temperature : 1800k
  • Cool White Color Temperature : 6500k
  • CTC Control from 1800k to 6500k
  • Warm White Illuminance : 1181 Lux @ 2m
  • Cool White Illuminance : 1415 lux @ 2m
  • Momentary Strobe Illuminance : 2680 lux @ 2m
  • LED Lifetime : 50,000 hours

Optics

  • ActiveFrost electronic diffusion glass
  • RGB Beam Angle : 120°
  • RGB Field Angle : 158°
  • White Beam Angle : 90°

Control

  • Control Protocols : DMX512, RDM, Auto, Sound Active
  • DMX Channels : 10A / 10B / 16CH / 26CH / 201CH
  • Dimmer : 0–100% smooth dimming
  • Strobe : 1–20Hz
  • Display : LED menu display

Power

  • Voltage : AC 100–240V, 50/60Hz
  • Power Consumption : 390W @ 100V / 366W @ 220V
  • Connections
  • Power I/O : PowerCON in/out
  • DMX I/O : 3-pin & 5-pin XLR in/out

Physical

  • Dimensions : 16.1 × 7.9 × 7.9 in (41 × 20 × 20 cm)
  • IP Rating : IP20
SKU CLR-CKU4110
Brand ColorKey
Weight 18.550000
