Boss MS-3 Multi Effects Switcher in ONE + Gator 9V Power Combo & 3 Patch Cables

Boss MS-3 Multi Effects and Switcher in ONE

• Powerful integrated solution for creating a compact professional pedalboard
• Unlimited sound creation with six simultaneous pedal effects and audio loops for connecting three external pedals
• 112 built-in effects types for guitar and bass, including delays, reverbs, mod/pitch effects, overdrives, distortions, and more
• Intuitive user interface for easy patch creation
• Backlit LCD, editing knobs, and panel LEDs for on/off status of loops and effects
• Control assign, wave pedal, and other functions for deep real-time expression
• Equipped with numerous jacks for amp channel switching, effects control, and more
• MIDI output for working with MIDI-enabled effects
• Built-in tuner, noise suppressor, and global EQ
• USB for patch creation and backup via free MS-3 Editor/Librarian software
• DA Conversion 24 bits
• Sampling Frequency 44.1 kHz
• Effects 112 types
• Patches 200
• ModesMemory : mode/Manual mode
• Loops : 3
• Output Impedance  : OUTPUT L/MONO, R : 1 k ohms
• Input Impedance INPUT : 1 M ohms

AD Conversion

• 24 bits + AF method
• AF method (Adaptive Focus method) This is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.

Nominal Input Level

• INPUT : -10 dBu
• LOOPS L1--3 RETURN : -10 dBu

Maximum Input Level

• INPUT : +7 dBu
• LOOPS L1--3 RETURN : +7 dBu

Nominal Output Level

• OUTPUT L/MONO, R : -10 dBu
• LOOPS L1--3 SEND : -10 dBu

Recommended Load Impedance

• OUTPUT L/MONO, R : 10 k ohms or greater
• LOOPS 1--3 SEND : 10 k ohms or greater

Controls

• Number switches 1--4, MEMORY/MANUAL switch
• ON/OFF button, MENU button, EDIT button, EXIT button, ENTER button
• 1--3 knobs
• POWER switch
• Display Graphic LCD (132 x 32 dots, backlit LCD)

Indicator

• Number indicators 1--4, MEMORY/MANUAL indicator
• On/Off indicators (FX1, MOD1, L1--3, FX2, MOD2, DLY, REV)

Connectors

• INPUT jack : 1/4-inch phone type
• LOOPS L1--3 SEND jacks  : 1/4-inch phone type
• LOOPS L1--3 RETURN jacks  : 1/4-inch phone type
• OUTPUT (L/MONO, R) jacks : 1/4-inch phone type
• CTL OUT CTL1/2 jack : 1/4-inch TRS phone type
• CTL IN EXP1 CTL1/2 jack, CTL IN EXP2 CTL3/4 jack : 1/4-inch TRS phone type
• USB COMPUTER port : USB type B
• MIDI OUT connector
• DC IN jack

Power Supply

• AC adaptor
• Current Draw 280 mA
• Accessories
• AC adaptor
• Rubber feet x 4
• Owner's manual
• Leaflet "USING THE UNIT SAFELY"

Options (sold separately)

• Footswitch  : FS-5U, FS-5L, FS-6, FS-7
• Expression pedal : EV-30, FV-500L, FV-500H, Roland EV-5

Size

• Width : 246 mm 9-11/16 inches
• Depth : 97 mm3-7/8 inches
• Height : 68 mm 2-11/16 inches

Gator Cases GTR-PWR-1MAX 9V Power Supply Combo Pack

• 9V DC Power Adapter and 8-Output Daisy Chain Cable Combo Pack
• Slim Design Frees up Space on Power Strip by Occupying One Outlet
• Works with Optional Female-to-Male Daisy Chain Adapter Cable for Connecting Multiple Pedals
• Single Output Supplies Maximum of 1700mA to Power Fully Loaded Pedalboard
• AC Power Input with Variable Voltage Between 115V/230V (50-60Hz) for International Use
• 8-Foot Cable to Reach Far Away Outlets

Gator Cableworks Backline Series 6" Instrument/Patch Cable, 3-Pack

• 6-inch Instrument/Patch Cable, 3-Pack
• 1/4-inch Right Angle to 1/4-inch Right Angle
• Professional Low-Noise Cable
• Fine Stranded Oxygen Free Copper Conductor for High-Quality Signal Transmission
• Thick and Durable 6.5 mm Soft PVC Jacket
• Shrink Sealed Wire Connection for Protection and Strain Relief
• Reliable and Sturdy Connectors
