Radial Gold Digger

4 Channel Mic Selector

Brand New

Out of stock

"Don't See The Deal You Want?" Request A Deal

  • Google Playstore
  • Apple store

Product Description for the Radial Gold Digger

The Gold Digger is a 4-channel mic selector that enables the engineer to quickly compare the sound of four different microphones while sharing the same preamp. A 'straight wire' passive circuit design is void of any audio buffers or transformers. Instead, the Gold Digger employs military grade gold contact relays to manage the switching process, thus ensuring the pristine mic signal is maintained without introducing color, distortion or artefact of any kind.

Features include four rear-mounted XLR-F mic inputs plus an XLR-m output to feed the preamp. To eliminate bleed between microphones, each channel is equipped with a 'radio style' selector switch that ensures only one mic is on at a time. The external supply provides power for the LED indicators, charges the relays and enables the Gold Digger to generate 48 volt phantom which can be turned on or off for each mic as needed. To ensure an 'honest' comparison between microphones, individual 'set & forget' trim controls let you adjust each mic level so that they produce the same relative output. Once set up, the Gold Digger not only improves workflow, but also gives the artist more confidence with the sound of the vocal, resulting in a better overall performance.

The Gold Digger – A tool designed to get the very best out of each and every performance.


  • Four selectable inputs with trim adjusts
  • Straight wire distortion-free signal path
  • Will not introduce color or artifact
  • Increases artist's confidence when recording
  • Audio circuit type : Passive signal path with active relay switching
  • Frequency response : 10Hz to 100kHz +/- 0.0dB
  • Dynamic range : >140dB
  • Equivalent input noise : -115dBu
  • Residual noise : -140dB
  • Maximum input : +26dBu
  • Maximum output : +26dBu
  • Total harmonic distortion : 0.0003%
  • Phase deviation : < 0.001 Degrees at all frequencies
  • Intermodulation Distortion 0.001%
  • Input impedance : 600 Ohms (typical)
  • Common mode rejection : -92dBu @ 55Hz
  • Gain : 0.0dB – Unity gain device


  • Inputs : 4 x XLR female
  • Outputs : Balanced XLR male
  • Switches : Individual on/off for each input
  • Individual 48V phantom power for each input
  • Controls : Variable trim on each input
  • XLR configuration : AES standard (pin-2 hot)


  • Power : +15V DC/400mA power supply included
  • Construction : 14 gauge steel chassis & outer shell
  • Finish : Durable powder coat
  • Size:  (W x H x D) 4.5"         x 2"         x 6"         (121        x 64        x 147mm)
  • Shipping size : W x H x D : 4.75"      x 2.5"      x 10.75" (121        x 64        x 273mm)
  • Conditions : For indoor use at temperatures between +5° c and +40° c
Brand Radial
Weight 3.3000
