MXR M173

Classic 108 Fuzz Guitar Effects Pedal

MXR M173 Classic 108 Fuzz Guitar Effects Pedal

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

  • MXR M173 Classic 108 Fuzz Guitar Effects Pedal
  • MXR M173 Classic 108 Fuzz Guitar Effects Pedal
Brand New

$129.99

Availability: In stock now

"Don't See The Deal You Want?" Request A Deal

Download the Proaudiostar APP for exclusive deals!



Question about this item?

Call: 888-890-6222

.

Product Description for the MXR M173

The Classic 108 Fuzz features the guts of our BC-108-loaded Fuzz Face® Distortion with modern MXR upgrades and a Buffer switch so that it plays well with wahs.

Guitarists of all styles will dig the familiar late-Sixties/ early-Seventies crunch delivered by the new MXR Classic 108 Fuzz. We've taken the guts of our BC-108 loaded Fuzz Face, placed them in a more pedal-board friendly shape, and added the modern conveniences of a battery door, optional AC operation, and true bypass with LED. The Buffer switch eliminates the audible oscillation caused when some wah-wahs are placed in front of a Fuzz Face. The Classic 108 Fuzz comes in a heavy-duty Phase 100-sized box with a sweet hammertone turquoise finish.

Features

Description

  • BC108 Fuzz Face® circuitry in a pedal-board friendly chassis
  • Original Fuzz Face hammertone turquoise finish
  • True bypass

Power

The MXR Classic 108 Fuzz is powered by one 9-volt battery (remove bottom plate to install), a 9-volt AC Adapter such as the Dunlop ECB003/ECB003EU or  a power supply such as the DC Brick.

Directions

  • Run a cable from your guitar to the Classic 108 Fuzz’s INPUT jack and run another cable from its OUTPUT jack to your amplifier.
  • Start with all controls at 12 o’clock.
  • Turn the effect on by depressing the footswitch.
  • Rotate the FUZZ knob clockwise to increase amount of fuzz or counterclockwise to decrease it
  • Rotate the VOLUME knob clockwise to increase overall effect volume or counterclockwise to decrease it.
  • Engage the BUFFER switch to eliminate the oscillation that sometimes occurs when a wah wah is in front of the Classic 108 Fuzz. You may notice a brightening of the fuzz tone.

Specifications

  • Input Impedance
  • Buffer ON : 800 kΩ
  • Buffer OFF : 10 kΩ
  • Output Impedance at 1 kHz
  • Max Volume : 16 kΩ
  • -6 db Volume : 160 kΩ
  • Max Output Level : -4 dBV
  • Max Gain at 1 kHz : 55 dB
  • Bypass : True Hardwire
  • Current Draw : 2.2 mA
  • Power Requirement : 9 volts DC
  • ·

Controls

  • VOLUME knob controls overall effect volume
  • FUZZ knob controls amount of fuzz
  • BUFFER switch removes high-end roll off and oscillation caused by some wah wahs
  • FOOTSWITCH toggles effect on/bypass (blue LED indicates on)
SKU MXR-M173
Brand MXR
Weight 1.6000
Dimensions (WxHxD) No
